PRORECK 410 D2 10 Inch Car Subwoofer
Dual 2 Ohm Car Audio Subwoofer | 400W RMS | 1200W Peak | 15.1mm Xmax
The PRORECK 410 D2 is a 10 inch car subwoofer designed for car audio systems that need stronger low-frequency extension, flexible amplifier matching, and practical enclosure support. This car audio subwoofer features a dual 2 ohm voice coil design, handles 400 watts RMS and 1200 watts peak, and is engineered for both sealed and ported enclosure applications.
If you are searching for car subwoofers, a subwoofer for car daily-driving systems, or a 10 inch car subwoofer for a custom trunk or compact bass build, the 410 D2 offers a strong balance of output, wiring flexibility, and installation-friendly dimensions.
Important: this model is a passive dual voice coil subwoofer, not a powered subwoofer. Enclosure not included. An external amplifier is required.
Key Features
- 400W RMS / 1200W Peak Power Handling for stronger bass output in custom car audio systems.
- Dual 2 Ohm Voice Coil Design provides flexible wiring options for amplifier matching and custom system loads.
- 15.1mm Xmax supports deeper cone travel for stronger low-frequency response and controlled bass performance.
- 10 Inch Car Subwoofer Format offers a balanced mix of output, extension, and installation practicality.
- Works in Sealed or Ported Boxes so users can choose tighter response or stronger low-end output based on enclosure type.
- Built for Car Audio Use with a thickened carbon steel frame, double stack ferrite magnet structure, and multi-hole ventilation/cooling design.
Why Choose the PRORECK 410 D2
The PRORECK 410 D2 is a strong option for buyers who want more bass authority than an 8 inch setup while still keeping the installation manageable for daily-driver and custom trunk systems. Its 10 inch format gives it more cone area, while the dual 2 ohm configuration provides wiring flexibility for amplifier matching.
For shoppers comparing car subwoofers for custom installs, the 410 D2 is well suited for sealed or ported enclosure builds where a balanced mix of punch, depth, and practical fitment is important.
Product Specifications
| Brand |
PRORECK |
| Model |
410 D2 |
| Type |
Passive Dual Voice Coil Car Subwoofer |
| Speaker Size |
10 Inch |
| Rated Impedance |
Dual 2 Ohm |
| DC Resistance (Re) |
D2 / 1.8Ω |
| RMS Power Handling |
400W |
| Peak Power Handling |
1200W |
| Frequency Response |
41.5Hz–700Hz |
| Fs |
41.5Hz |
| Sensitivity (1w/1m) |
84.5dB |
| Qts |
0.60 |
| Qms |
4.13 |
| Qes |
0.7 |
| Vas |
12.4L |
| Xmax (Linear Excursion) |
15.1mm |
Physical Dimensions
| Outer Frame Dimension |
10.39 in / 264 mm |
| Mounting Cutout |
9.65 in / 245 mm |
| Mounting Depth |
5 in / 127 mm |
| Pore Diameter |
8.9 in / 226 mm |
| Trim Ring Height |
1.05 in / 26.7 mm |
Recommended Box Specifications
Sealed Enclosure
Minimum Sealed Box Volume: 0.95 ft³ (27L)
Maximum Sealed Box Volume: 1.70 ft³ (48.6L)
Minimum Sealed Box Panel Dimensions
using 3/4" MDF
Panel A: 12.3 x 13.4 in
Panel B: 13.5 x 13.5 in
Panel C: 13.5 x 14.4 in
Ported / Vented Enclosure
Minimum Vented Box Volume: 1.23 ft³ (35L)
Maximum Vented Box Volume: 1.51 ft³ (42.9L)
Minimum Port Opening: 2.36 x 7.4 in
Minimum Port Length: 7.4 in
Box Building Notes
- Enclosure not included. Box specifications are provided for custom enclosure builds only.
- Use 3/4" (1.9 cm) or thicker MDF and seal all joints with silicone.
- Add internal bracing to larger unsupported panels for improved enclosure strength.
- Choose a sealed box for tighter, more controlled bass response.
- Choose a vented box for stronger low-frequency output and higher bass efficiency.
Packaging Information
Single (1 Speaker)
Package Dimensions: 31.5 x 31 x 22 cm
Package Volume: 0.021483 m³
Gross Weight: 5.5 kg
Pair (2 Speakers)
Package Dimensions: 32.5 x 32.5 x 47.5 cm
Package Volume: 0.050171875 m³
Gross Weight: 11.7 kg
Net Weight: 10.7 kg
Construction Highlights
- Thickened carbon steel frame
- Protective PVC textured magnet cover
- Double stack ferrite magnet structure
- High-temperature resistant coil aluminum frame
- Optimized motor magnetics with extended pole and bumped backplate
- Multi-hole ventilation/cooling technology
- Dual tear & fatigue resistant poly-cotton spiders
- Multi-point high-temp/high-strength neck joint bonding technique
- Pure copper chrome-plated/isolated compression input terminal assembly
Installation & System Matching
The PRORECK 410 D2 is best used with an external mono or bridged amplifier matched to a dual 2 ohm subwoofer setup. Because it is a DVC model, it offers multiple wiring options depending on your amplifier’s safe operating range.
For optimum subwoofer performance, an active 80–100Hz low-pass crossover at 12dB/octave is recommended.
What’s Included
- PRORECK 410 D2 10" Car Subwoofer
- Available in Single (1 Speaker) or Pair (2 Speakers) options
- Enclosure not included
FAQ
Is the PRORECK 410 D2 a powered subwoofer?
No. This is a passive car audio subwoofer and requires an external amplifier.
What size is the PRORECK 410 D2?
It is a 10 inch car subwoofer.
What impedance is the 410 D2?
The 410 D2 is the dual 2 ohm version, with Re listed as 1.8Ω for the D2 model.
Does it include a box or enclosure?
No. This product includes the subwoofer speaker only. Enclosure not included.
Can I use it in a sealed or ported box?
Yes. The 410 D2 has recommended specifications for both sealed and ported enclosures.
Can I buy the 410 D2 as a single speaker or a pair?
Yes. This model can be offered in Single (1 Speaker) and Pair (2 Speakers) purchase options, depending on the listing configuration.
